The gimbal protocol allows MAVLink control over the attitude/orientation of cameras (or other sensors) mounted on the drone

  • Gimbal Device: the actual gimbal device, hardware and software.
  • Gimbal Manager: software to deconflict gimbal messages and commands from different sources, and to abstract the capabilities of the Gimbal Device from gimbal users.
GIMBAL_DEVICE_ATTITUDE_STATUS ~/device/attitude_status Send out its attitude and status at a regular rate, e.g. 10 Hz This message is a meant as broadcast
GIMBAL_MANAGER_STATUS Current status about a high level gimbal manager. This message should be broadcast at a low regular rate (e.g. 5Hz).
GIMBAL_DEVICE_INFORMATION Information about a low level gimbal. This message should be requested by the gimbal manager or a ground station using MAV_CMD_REQUEST_MESSAGE.
GIMBAL_MANAGER_INFORMATION Information about a high level gimbal manager. This message should be requested by a ground station using MAV_CMD_REQUEST_MESSAGE.
GIMBAL_DEVICE_SET_ATTITUDE Low level message to control a gimbal device's attitude. This message is to be sent from the gimbal manager to the gimbal device component.
GIMBAL_MANAGER_SET_ATTITUDE High level message to control a gimbal's attitude.
GIMBAL_MANAGER_SET_PITCHYAW High level message to control a gimbal's pitch and yaw angles.

GIMBAL_MANAGER_SET_ATTITUDE (282)

Mavlink

Field Name Type Units Values Description
target_system uint8_t System ID
target_component uint8_t Component ID
flags uint32_t GIMBAL_MANAGER_FLAGS High level gimbal manager flags to use.
gimbal_device_id uint8_t Component ID of gimbal device to address (or 1–6 for non-MAVLink gimbal), 0 for all gimbal device components. Send command multiple times for more than one gimbal (but not all).
Messages with same value are from the same source (instance).
q float[4] Quaternion components: w, x, y, z. (1 0 0 0 is the null-rotation. The frame depends on whether the flag GIMBAL_MANAGER_FLAGS_YAW_LOCK is set)
angular_velocity_x float rad/s invalid:NaN X component of angular velocity. Positive is rolling to the right. NaN means ignore.
angular_velocity_y float rad/s invalid:NaN Y component of angular velocity. Positive is pitching up. NaN means ignore.
angular_velocity_z float rad/s invalid:NaN Z component of angular velocity. Positive is yawing to the right. NaN means ignore.

Ardupilot

Control a Gimbal / Camera Mount

Running SITL with GIMBAL
1
./arducopter --model quad --speedup 1 --slave 0 --default default.param --sim-address 127.0.0.1 -I0 --gimbal

Params

Ardupilot support two gimbals

parameter default/setting description
MNTx_ROLL_MAX/ MNTx_ROLL_MIN
MNTx_PITCH_MAX/ MNTx_PITCH_MIN
MNTx_YAW_MAX/ MNTx_YAW_MIN
MNTx_RETRACT_X/Y/Z
MNTx_NEUTRAL_X/Y/Z

Gimbal Mode vs Control Mode

  • Gimbal Mode = how the gimbal interprets the world (lock/follow/stabilize)
  • Control Mode = how you command it (MAVLink, RC, ROI, scripts)
Feature Stabilize Lock
What it does Cancels out drone motion (vibrations, tilt) Maintains a fixed orientation in world coordinates
Frame reference Relative to vehicle Relative to world
Example usage Keeps video stable while drone moves Keeps camera pointed north even if drone turns
Input source Uses IMU/gyro feedback to cancel motion Uses attitude + world frame input (e.g., target quaternion)
Updates? Still follows pilot commands / RC / MAVLink pitch Ignores movement unless new command is sent
Use case Smooth footage Survey, inspection, target tracking

SITL

ArduPilot uses the FLU frame for mount/gimbal orientation

  • Pitch = -90° → camera pitches upward (toward +Z, up)
  • Pitch = +90° → camera pitches downward (toward -Z, down)

Camera centric coordinate system

alt text

Axis

Axis Direction (when facing forward through the lens)
X Right
Y Down (often, or up in some variants)
Z Forward (out of the lens)

Rotational Axes

Rotation Around Axis Positive Direction
Yaw Z Turn right (CW when viewed from above)
Pitch X Tilt up
Roll Y Tilt right

SITL(FLU) / HARDWARE(Camera-Centric)

Aspect Camera-Centric FLU (Vehicle-Centric)
Pitch + Camera tilts up Vehicle nose tilts up (camera looks down)
Used by Gimbal manufacturers, vision ArduPilot SITL, PX4 internals
Orientation origin Camera lens Vehicle body center
Application Imaging, targeting Navigation, control
  • GIMBAL_DEVICE_ATTITUDE_STATUS (3hz)
  • GIMBAL_MANAGER_STATUS(1hz)

More terms

Nadir and zenith

alt text

Mavros

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# add gimbal_control plugin
/mavros/**:
  ros__parameters:
    plugin_denylist:
      # common
      - '*'

    plugin_allowlist:
      - sys_time
      - sys_status
      - command
      - gimbal_control
~/device/get_info GIMBAL_DEVICE_INFORMATION
~/manager/get_info command_long Trigger manager/info /mavros/gimbal_control/manager/info
~/manager/configure
~/manager/pitchyaw
~/manager/set_roi
~/manager/camera_track

GIMBAL_MANAGER_SET_ATTITUDE

Mavlink GIMBAL_MANAGER_SET_ATTITUDE (282) High level message to control a gimbal's attitude. This message is to be sent to the gimbal manager , rate can be ignore by sending NaN.

Code snippet to be move from here

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
# Image point (u, v), image size, and camera intrinsics (fx, fy, cx, cy)
x_cam = (u - cx) / fx
y_cam = (v - cy) / fy
z_cam = 1.0

# 3D ray in camera frame
ray_camera = np.array([x_cam, y_cam, z_cam])
ray_camera /= np.linalg.norm(ray_camera)

# Convert to FLU/world frame (if needed)
ray_world = camera_to_world @ ray_camera  # If using TF or known pose

quat = look_at_quaternion(ray_world)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
import numpy as np
from scipy.spatial.transform import Rotation as R

def look_at_quaternion(forward_target, up=np.array([0, 0, 1])):
    # Normalize direction
    z = forward_target / np.linalg.norm(forward_target)

    # Compute orthogonal axes
    x = np.cross(up, z)
    if np.linalg.norm(x) < 1e-5:
        # up and forward are aligned → default right vector
        x = np.array([1, 0, 0])
    x /= np.linalg.norm(x)
    y = np.cross(z, x)

    rot_matrix = np.vstack((x, y, z)).T  # FLU: forward=Z
    return R.from_matrix(rot_matrix).as_quat()  # [x, y, z, w]

1
you can interpolate quaternions with SLERP to smooth the motion

This is the code i need

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
from geometry_msgs.msg import Quaternion
from scipy.spatial.transform import Rotation as R
import numpy as np

def correct_gimbal_quaternion(q_current, u, v, cx, cy, fx, fy):
    # Calculate angular error
    dx = (u - cx) / fx
    dy = (v - cy) / fy

    yaw_error = -dx
    pitch_error = -dy

    # Convert errors to rotation delta
    error_rot = R.from_euler('zy', [yaw_error, pitch_error])
    q_current_rot = R.from_quat(q_current)  # [x, y, z, w]

    q_new = q_current_rot * error_rot
    return q_new.as_quat()  # [x, y, z, w]
